Viking K2 Slide Gate Operator - Operator Only | VIK-VA-K2SPS
Viking K2 Slide Gate Operator - Operator Only | VIK-VA-K2SPS
The K-2 gate operator has the capacity to operate slide gates up to 700 lbs. and 30 ft. in length at 100% duty cycle under extreme conditions. This efficient operator provides a solution for high-traffic residential slide gate applications. The Viking K-2 gate operator offers efficiency and technology combined in a single package. The power supply features convenient fuse access and LED status indicators for incoming high voltage. Solar efficiency, direct drive motor, and safety compliance make the K2 the operator of choice for your residential slide gate application.
Please note, VA-K2SPS is the new version of VA-K2NX which includes a Smart Positioning System (SPS).
Note: Operator includes 25’ #40 nickel plated chain with chain bolts
Features
- Adaptive motor control
- Built-in thermostat-controlled heater
- Built-in voltmeter
- Lightning strike protection
- Multiple power options
- On-board display
- True battery back-up
- UL325 compliant
- Two monitoring inputs w/ up to 4 devices per input
- 120VAC outlet provided
- Adjustable speed control
- Anti-tailgating feature
- NEW: Smart Positioning System
- Fail secure mode
- Fail-safe mode
- Lockable cover
- Manual release - electronic
- Multiple power outage options
- Two 4Ah batteries included
- Chassis with post-mount provisions
PLEASE NOTE: Viking K2 Residential Slide Gate Operator must have a Photo Beam to function. It is recommended you add a Photo Beam for convenience and/or to minimize complications. This accessory is available in the product options.
Manufacturer's Warranty Period
- 3 Years
Technical Specifications
- Maximum Gate Capacity: 30 ft at 700 lb
- UL 325 Classification: Class I
- Duty Cycle: 100%
- Operating Voltage: 24VDC
- Main Power Source: 120VAC - 1.5A or 240VAC - 1.0A
- Main Power Frequency: 50Hz / 60Hz
- Main Power Fuse: 4A Timed
- Alternative Power Source: 24VAC / VDC (60VA) or Solar
- Accessory Power: 24VDC - 750mA
- Power Consumption: - Idle 75mA
- Motor Current (Typical): 5.0A
- Operating Temperature: -20°F (-28°C) to 160°F (71°C)
- Gate Speed: 12 in./sec.
- Battery Backup: 100 Continuous Cycles
Product Video
Product Literature
Original: $1,718.99
-70%$1,718.99
$515.70
Description
Viking K2 Slide Gate Operator - Operator Only | VIK-VA-K2SPS
The K-2 gate operator has the capacity to operate slide gates up to 700 lbs. and 30 ft. in length at 100% duty cycle under extreme conditions. This efficient operator provides a solution for high-traffic residential slide gate applications. The Viking K-2 gate operator offers efficiency and technology combined in a single package. The power supply features convenient fuse access and LED status indicators for incoming high voltage. Solar efficiency, direct drive motor, and safety compliance make the K2 the operator of choice for your residential slide gate application.
Please note, VA-K2SPS is the new version of VA-K2NX which includes a Smart Positioning System (SPS).
Note: Operator includes 25’ #40 nickel plated chain with chain bolts
Features
- Adaptive motor control
- Built-in thermostat-controlled heater
- Built-in voltmeter
- Lightning strike protection
- Multiple power options
- On-board display
- True battery back-up
- UL325 compliant
- Two monitoring inputs w/ up to 4 devices per input
- 120VAC outlet provided
- Adjustable speed control
- Anti-tailgating feature
- NEW: Smart Positioning System
- Fail secure mode
- Fail-safe mode
- Lockable cover
- Manual release - electronic
- Multiple power outage options
- Two 4Ah batteries included
- Chassis with post-mount provisions
PLEASE NOTE: Viking K2 Residential Slide Gate Operator must have a Photo Beam to function. It is recommended you add a Photo Beam for convenience and/or to minimize complications. This accessory is available in the product options.
Manufacturer's Warranty Period
- 3 Years
Technical Specifications
- Maximum Gate Capacity: 30 ft at 700 lb
- UL 325 Classification: Class I
- Duty Cycle: 100%
- Operating Voltage: 24VDC
- Main Power Source: 120VAC - 1.5A or 240VAC - 1.0A
- Main Power Frequency: 50Hz / 60Hz
- Main Power Fuse: 4A Timed
- Alternative Power Source: 24VAC / VDC (60VA) or Solar
- Accessory Power: 24VDC - 750mA
- Power Consumption: - Idle 75mA
- Motor Current (Typical): 5.0A
- Operating Temperature: -20°F (-28°C) to 160°F (71°C)
- Gate Speed: 12 in./sec.
- Battery Backup: 100 Continuous Cycles
