Miller Edge Swing Gate Sensing Edge Non-Monitored 5' with Mounting Channel | MLE-MGO20-K10-2E-05
Miller Edge Swing Gate Sensing Edge Non-Monitored 5' with Mounting Channel | MLE-MGO20-K10-2E-05
Miller Edge Swing Gate Sensing Edge Non-Monitored 5ft with Mounting Channel | MLE-MGO20-K10-2E-05
The MGO20 sensing edge offers three-sided activation for enhanced protection. This slide-in style edge has a small profile which allows for versatility to suit a wide variety of applications from motorized doors and gates to industrial safeguarding on plant equipment. MGO20 is compatible with two mounting channel options and can be custom manufactured to user specifications for color, length, and outlet location.
Features
- 3-sided activation
- Easy to install
- Optimum size for 1-1/2 inch gate surfaces
- Mounts vertically or horizontally
- Sealed assembly impervious to dust and debris
- Mounting channel options
- Custom manufactured to user specifications for color, length, and outlet location
- Patented Alumaglas™ for superior performance
- UL 325 Recognized Component
- 1-year warranty
- Made in USA
Applications
- Motorized gates
- Slide gate draw-in posts
- Pockets & pivot points
- Barrier arms
Configurations
- Non-Monitored
- 2-Wire
Technical Specifications
- Color: Black or Yellow
- Length: Order in 1/4 in. increments (manufacturing tolerance ±1/4 in.)
- Maximum Length: 10 ft. (additional shipping charges apply to lengths over 8 ft.)
- Sensitivity: Nominal 4-7 lbf
- Lead Wire: SJTO, 18 gauge, 2 ft. length
- Wire Outlet Location: Left, Right, or end
- Electrical Maximum: 24 volts AC/DC, 1/2 amp
- Electrical Configuration: Normally open
- Operating Temperature: -30 °F to 155 °F (-34 °C to 68 °C)
- Exterior Materials: Flexible PVC
- Contact Element: Alumaglas™
- Agency Approvals: UL 325 Recognized Component
Product Literature
Original: $198.99
-70%$198.99
$59.70
Description
Miller Edge Swing Gate Sensing Edge Non-Monitored 5ft with Mounting Channel | MLE-MGO20-K10-2E-05
The MGO20 sensing edge offers three-sided activation for enhanced protection. This slide-in style edge has a small profile which allows for versatility to suit a wide variety of applications from motorized doors and gates to industrial safeguarding on plant equipment. MGO20 is compatible with two mounting channel options and can be custom manufactured to user specifications for color, length, and outlet location.
Features
- 3-sided activation
- Easy to install
- Optimum size for 1-1/2 inch gate surfaces
- Mounts vertically or horizontally
- Sealed assembly impervious to dust and debris
- Mounting channel options
- Custom manufactured to user specifications for color, length, and outlet location
- Patented Alumaglas™ for superior performance
- UL 325 Recognized Component
- 1-year warranty
- Made in USA
Applications
- Motorized gates
- Slide gate draw-in posts
- Pockets & pivot points
- Barrier arms
Configurations
- Non-Monitored
- 2-Wire
Technical Specifications
- Color: Black or Yellow
- Length: Order in 1/4 in. increments (manufacturing tolerance ±1/4 in.)
- Maximum Length: 10 ft. (additional shipping charges apply to lengths over 8 ft.)
- Sensitivity: Nominal 4-7 lbf
- Lead Wire: SJTO, 18 gauge, 2 ft. length
- Wire Outlet Location: Left, Right, or end
- Electrical Maximum: 24 volts AC/DC, 1/2 amp
- Electrical Configuration: Normally open
- Operating Temperature: -30 °F to 155 °F (-34 °C to 68 °C)
- Exterior Materials: Flexible PVC
- Contact Element: Alumaglas™
- Agency Approvals: UL 325 Recognized Component
