Doorking RF MicroCLIK Receiver | DKS-8057-081

Doorking RF MicroCLIK Receiver | DKS-8057-081

An RF MicroCLIK Receiver with 318Mhz, 50 memory capacity is a fully programmable stand-alone receiver that can store up to 16,000 transmitter codes.

Features

• Provides remote operation of vehicular access gates from the safety and convenience of a vehicle
•

• Transmitters available with 1, 2 or 3 buttons
•

• PROXmtr™ includes a built in proximity card with the MicroCLIK transmitter combining both RF and card access control into a single compact unit
• HomeLink® compatible
• Stand-alone receiver
• Stores up to 16,000 MicroClik transmitter codes
• Built-in programming keypad
• Add or delete transmitters individually or in block format
• Programmable facility codes, relay strike time, transmitter button number
• Form C dry contact relay
• 12-24 Volt AC or DC

Technical Specifications

• Type: Stand-alone
• Max Codes: 16,0000
• History Buffer: 2300 Events
• Facility Codes: No
• Transactions Reporting: Yes
• Time Zones: 10
• Output: One (1) Dry Contact Relay
• Power: 12-24 VAC/VDC
• Range: 50-75 Ft.

Manufacturer's Warranty Policy

• 2 years

Product Literature

• Doorking 8057-081 Brochure
• Doorking 8057-081 Installation Manual
• Doorking 8057-081 Literature
• Doorking 8057-081 Warranty Policy
